pics of your 7ms engine bay

[b005t3d]



[GrimJack]

Come on Grim....Look at the title of this thread! Now its been tainted by mad JDMness. *sigh* :biglaugh:

Hey, I donated some time to getting that together, I figure that counts.



[aye mate]

Boo5t3d: Is it just me or do you have alot more hoses than I remember mine having?



[GrimJack]

Boo5t3d: Is it just me or do you have alot more hoses than I remember mine having?

No, that's pretty much normal - he's just replaced most of the hardlines...



[Supra_brothers]



[GrimJack]

Supra_brothers, is it my imagination, or is your old BOV port just plumbed straight into your accordian hose pre-turbo?



[socc924]

^^^it looks it to me too



[Reign_Maker]

Thats not right... talk about a major boost leak...



[Reign_Maker]

My last Supra... IdealSupra loves my paint skillz... lol...

This is my motor when I first got it... Try not to cry, I've got my cans of spray paint ready...

Here is an after shot... Keep an eye on this folks, it's going to be looking alot better... This off-season I'll be doing some serious investing in the area... *Krylon anyone? LOL! Just kidding, Im actually gunna PC alot of parts, and, wellllll, just keep an eye out*



[b005t3d]

Boo5t3d: Is it just me or do you have alot more hoses than I remember mine having?

im just trying to simplify the bullshit of vaccume hoses under there. :icon_evil id like to get it to the point of like one big central hose, hidden some where. vaccum hoses are disgusting looking. speaking of wich, can i rid myself of the lines for the crankcase breathers and just put filters on it? or will it majorly f something up?



[GrimJack]

speaking of wich, can i rid myself of the lines for the crankcase breathers and just put filters on it? or will it majorly f something up?

Depends. How much blowby does your engine have? Essentially, if you get any, breathers would just become oil drips on your engine.



[89Turbo]

Boo5t3d im curious on what all you did to your Supra to make it 3,000lbs man, PM me or post here.



[supradan22]

Me to



[Mark2JZ]



[aye mate]

Nice Mark...TO4r?



[b005t3d]

sorry it took so long y'all. the 300 pound weight was taken when the interior was out and the passanger seat was moved to the driver side to get rid of the pig of a driver seat. other than a full interior teardown, i had all the ac stuff gone, all of the towhooks gone, lots of little things like the power motor for the antena, those little things. both bumper supports are out, carbon fiber hood. really just stripping anything and everything that it doesnt need. i have parts of the car in three different states right now.



[whitemk3]

theres mine



[Cedrock15]

Wow..is that a leaf blower/vacuum infront of where charcoal cannister should be? j/k
Where and what lies in that pit( catch can?)?
I like the custom IC pipes, very clean.

As for my engine bay, you all have a long way to get as far as I got with my bay in the pic. (these are day one photos I took when i got cat in 7/05) Update pics coming soon



[sarichmond]

Here she blows captain, most of you already seen it already.

Boosted Supra Where did you get your IC hard pipes from? Damn I like the way yours looks.



[Boosted Supra]

Boosted Supra Where did you get your IC hard pipes from? Damn I like the way yours looks.

They were custom made, I do not have the measurements anymore. Sorry
