help with vacuum hose

[a_sesshoumaru]

i found this in the forum but i still dont kwon where the air bypass valve is.
http://i3.photobucket.com/albums/y81/dirgle/vac-hose.gif here is the link of the vacuum hose layout, http://www.supramania.com/forums/showthread.php?t=128, but if you have pictures, please help me out, i guess is all i have left to start my supra again.:1zhelp:



[trydrew]

Im not sure what you're asking. Do you need to see specific vacuum lines or all of them?

For the air bypass hose question, I circled where it comes from (circled on right side) and drew a line to the bypass valve (circled on the left). Sorry the lines are so hard to see but they are in the middle of the picture, just look closely.



[starscream5000]

The air bypass valve is th silver/copper colored round cylindrical shaped thingy with two big round hoses connected to each end of it. One hose comes off the 3000 pipe to the BPV and the other is connected to the accordian hose and goes to the BPV.



[a_sesshoumaru]

Thanks i fixed it, now it runs so good and fast. I didn´t know it was the same Blow off valve. Thanks a lot
