Engine under cover: Anyone still have theirs installed? Pic request.

[supraguy@aol]

As the title states, I need to see a pic of the under cover installed.
Specifically, I can't see how the front edge is supposed to tie into the lower valence of the bumper.
Online, it shows the part number is exactly the same for 87-92, but I don't have any mounting holes in the
bumper that align with those in the under cover.
A pic would be super helpful, so thanks in advance.



[GreenChevelleSS]

I have mine but i dont have any pics of it installed, itll be a month or so before I get mine back together too.



[supraguy@aol]

I hear ya.
To clarify, I have both covers installed under each fog light, as well as the inner fender shields.
Just need a pic of exactly how the front edge of the under cover ties into the lower edge of the bumper.



[adampecush]

I don't have photos as my intercooler hangs too low for me to put on the shield, but it attaches to a bracket that sits near the intersection of the bumper and lip.



[supraguy@aol]

Hmm...I don't see that on mine.
I have the long section of metal that clamps the lip to the bumper, but I don't see any bracket extending out from there.

I guess I'll take a few pics to post up.



[supraguy@aol]

Ok, I'm an idiot.
For whatever reason, I was looking at the wrong section of the bumper.
I was able to find all of the mounting points, right where they ought to be.
Problem solved, and I apologize for any waste of time that I caused you folks.
